100-ml, 450-m³ wired CS tear gas dispenser concealed inside sound cannons
The Qualiforce CS Wired Gas Diffuser is an active deterrent device designed to be integrated into an existing security system: alarm, sound cannon, wired control panel, or dry-contact relay.
Its role is simple: to make any presence in the area immediately untenable.
Operating Principle
The diffuser is equipped with:
-
of a solenoid valve
-
a pressurized CS gas cartridge
-
a trip low-voltage wired trigger
When it receives a command (dry contact, relay, control unit), it releases ahigh-pressure CS gas agent that is sprayed over a wide area.
The system is not resettable : the cartridge must be replaced after use.
Three triggering methods:
1 - Triggering manual remote activation via a mobile app.
2 - Triggered by seismic detection (self-protection of the sound cannon).
3 - Triggering Automatic following a confirmed intrusion + warning siren + safety delay.
Unlike pepper spray, CS gas disperses very easily and leaves no lingering traces.
CS gas is heavier than air.
It doesn't matter how high the ceiling is. Microdroplets linger at head height and gradually fall.
Broadcast Power and Efficiency
CS Gas – 100 ml
Brand: UX DEFENSE
Cover :
up to 100 m² or 450 m³
Broadcast Time : 22 seconds
Effective spray range : up to 12 meters
High pressure , known as the "Karcher" : the gas is forcefully propelled, not simply diffused
Thanks to a reduction in the liquid jet and a 70% increase in air mixing , the gas disperses very effectively throughout the area to be protected.
No damage, no traces
-
Do not leave any residue
-
Does not stain
-
Does not damage equipment or goods
-
Suitable for sensitive professional environments
We neutralize human presence, not the site.
Technical Specifications
Dimensions : 205 × 48 × 48 mm
Nozzle diameter : 11 mm
Weight : 950 g
Supply voltage : 6 to 24 V
Power consumption during a shot : 0.36 Ah / 4.4 W
Continuous power consumption : zero
Connection type : Wired (dry contact / relay / control panel)
Easy integration into an existing system
The Qualiforce CS Wired Gas Diffuser is designed to integrate with:
-
to an alarm
-
to a cannon at his
-
to a intrusion detection center
-
to a remote monitoring
-
any device with a dry contact
It acts as a complementary deterrent , triggered only when the security logic allows it.
Typical Use Cases
-
Construction Sites
-
Warehouses
-
Shops
-
Vacant Buildings
-
High-Value Areas
-
Sealed containers requiring rapid neutralization
